Beam BoundaryOptical evidence lab
Filter source-labelled observations while keeping machine, material, units, failures and unknowns attached.
Search by material, model, operation or observed outcome. Every result keeps its source and transfer boundary visible.
xTool D1 · 10 W blue diode · 3 mm
Source reference row supplies a one-pass cutting parameter; success criteria and kerf are not reported.
Transfer limit: Only a traceable starting test for xTool D1 10 W and the source-claimed 3 mm basswood board. Not transferable to plywood, D1 Pro, other wattages, or other software percentages.
How evidence is qualifiedxTool D1 · 10 W blue diode · 3 mm
Source reference row supplies a one-pass cutting parameter; edge quality is not reported.
Transfer limit: Only for the exact source-named xTool product on xTool D1 10 W. A generic 3 mm plywood label is insufficient identity.
How evidence is qualifiedxTool D1 · 10 W blue diode · 3 mm
Source reference row supplies a two-pass cutting parameter; cut quality and release test are not reported.
Transfer limit: Only black 3 mm source-claimed acrylic in xTool D1 10 W context. Never transfer to clear, mirrored, blue, white, unknown, or PVC-containing plastic.
How evidence is qualifiedxTool D1 · 10 W blue diode · 2 mm
Source reference row supplies a two-pass cutting parameter; charring and emissions were not measured.
Transfer limit: Not transferable to another MDF thickness, unknown fiberboard, D1 Pro, or any product without verified laser-compatible binder/SDS.
How evidence is qualifiedxTool D1 Pro · 20 W blue diode · 3 mm
Official xTool material library reports a one-pass cut reference for 3 mm basswood plywood on D1 Pro 20W.
Transfer limit: Only a starting test for xTool D1 Pro 20W with source-matched 3 mm basswood plywood. Do not transfer to D1, another module, generic plywood, or another controller scale.
How evidence is qualifiedxTool D1 Pro · 20 W blue diode · 3 mm
Official xTool material library reports a one-pass raster engraving reference for a 3 mm dark-red opaque glossy acrylic sheet on D1 Pro 20W.
Transfer limit: Only for source-matched dark-red opaque glossy 3 mm acrylic on D1 Pro 20W in raster mode. Not transferable to cut/vector modes, other colors, clear/mirrored acrylic, or CO2.
How evidence is qualifiedEpilog Fusion Pro 48 · 120 W CO2 · 6.35 mm (1/4 in nominal)
Epilog’s official project reports engraving the 1/4-inch acrylic on a Fusion Pro 48 120W at 100% speed, 50% power and 500 DPI.
Transfer limit: Project observation only for Epilog Fusion Pro 48 120W and the source’s 1/4-inch acrylic. Epilog percentages are controller-relative and cannot transfer to another model or machine.
How evidence is qualifiedEpilog Fusion Pro 48 · 120 W CO2 · 6.35 mm (1/4 in nominal)
Epilog’s official project reports cutting the 1/4-inch acrylic on a Fusion Pro 48 120W at 10% speed, 100% power and 100% frequency.
Transfer limit: Project observation only for Epilog Fusion Pro 48 120W and the source’s 1/4-inch acrylic. Do not transfer to another Epilog model, wattage, thickness or polymer product.
How evidence is qualifiedxTool D1 · 10 W blue diode · 2 mm
The official D1 10W reference row reports a one-pass cut and records a yellow edge as the observed result condition.
Transfer limit: Only for the exact source-claimed 2 mm white/gray-back cardboard on xTool D1 10W. Not transferable to 300 g stock, corrugated board, coated cartons or other thicknesses.
How evidence is qualifiedxTool D1 · 10 W blue diode · 8 mm
The official D1 10W row reports a three-pass cut and explicitly notes that a smaller focal length is needed.
Transfer limit: Only for the exact source-claimed 8 mm basswood board on xTool D1 10W with the source-required focus adjustment. Not transferable to plywood or another module.
How evidence is qualifiedxTool D1 · 5 W blue diode · 8 mm
The official D1 5W workbook records that the 8 mm basswood laminate was not cut through after ten passes at the listed setting.
Transfer limit: A failed observation only for the source-claimed 8 mm basswood laminate on xTool D1 5W at the exact listed row. Not a cue to add passes, and not transferable to solid basswood or plywood.
How evidence is qualifiedxTool D1 · 5 W blue diode · 3 mm
The official D1 5W workbook records a two-pass cut and reports yellowed edges on the exact 3 mm basswood-plywood row.
Transfer limit: Only for the exact source-named 3 mm xTool-launched basswood plywood on xTool D1 5W. Not transferable to D1 10W, D1 Pro, solid board, generic plywood or another thickness.
How evidence is qualifiedThat exact combination is not represented in the qualified library yet. Keep the gap visible, then choose a safe next step instead of borrowing a nearby setting.
Not counted
These evidence items remain auditable but are excluded from record, material, machine-context and failure coverage. They never appear in the filters above.
xTool D1 · 10 W blue diode · unknown (source gives basis weight only)
Source reference row supplies a one-pass parameter for 300 g cardboard; flame behavior and edge result are unreported.
Transfer limit: Basis weight is not thickness. Do not transfer to corrugated, laminated, coated, printed, waxed or adhesive-backed board.
How evidence is qualifiedxTool D1 · 10 W blue diode · unknown
Source reference row supplies a vector engraving parameter; contrast and surface result are not reported.
Transfer limit: Do not transfer to PU, faux, “vegan,” bonded, coated, or unidentified leather. Supplier confirmation/SDS must establish compatibility first.
How evidence is qualifiedxTool D1 · 10 W blue diode · unknown
Source remark prefers the coated reverse; output on the front stainless area may be poor.
Transfer limit: Applicability is limited to the source item and coated face. This is not a bare-stainless production marking recipe and not anodized aluminum guidance.
How evidence is qualifiedxTool D1 Pro · 20 W blue diode · 10 mm
Manufacturer reports a one-pass cut with smooth, clean surfaces and minimal burn marks.
Transfer limit: Performance observation only for xTool D1 Pro 20 W. It is not an actionable setting until missing setup fields are recovered from xTool.
How evidence is qualifiedxTool D1 Pro · 20 W blue diode · 5 mm
Manufacturer reports one-pass cuts for five listed colors.
Transfer limit: Color is not sufficient material identity. Observation is non-actionable without the missing setup and must never transfer to clear, mirrored, white, blue, or unknown acrylic.
How evidence is qualifiedxTool D1 Pro · 20 W blue diode · 4 mm
Tutorial example says the cut works on wood but does not pass through knotholes.
Transfer limit: A tutorial example, not a lab recommendation. Do not apply to plywood, MDF, hardwood, a different D1 Pro module, or safety-critical production.
How evidence is qualifiedGlowforge Plus · 40 W CO2 · unknown
Official workflow auto-detects or manually selects the exact Proofgrade material and exposes its default operation settings in the app.
Transfer limit: Workflow record only. Valid exclusively after exact Proofgrade recognition/selection on a Glowforge Plus 40 W; no numeric setting is reproduced or inferred.
How evidence is qualifiedGlowforge Plus · 40 W CO2 · unknown
Official workflow uses detected/selected Proofgrade identity and the operation default shown in the app.
Transfer limit: Exact Proofgrade workflow only on Glowforge Plus 40 W. No transfer to visually similar acrylic, diode lasers, or a different product/color/thickness.
How evidence is qualified
